Catrike Trail
The perfect Catrike for almost any rider. For comfort and portability, the Trail features a well-padded seat mounted to a fully adjustable, foldable frame. Proprietary hand rests offer adjustable support for long rides while the integrated computer mount and stock rear view mirror ensure you have all the information to be safe and efficient while riding.
The Trail Folds up for easy storage and transportation
Four-position adjustable seat back combine with a slightly-lower seating position for great touring. As with all Cats, we can add a Bosch or Bafang motor, adaptive accessories, rear rack, side-mount bags and a 3×3 or Rohloff gear hub!
.
Brakes Avid BB7 Disc Brakes
Brake Levers Catrike Locking Brake Levers
Front Derailleur Microshift Triple
Rear Derailleur SRAM GX 10 Speed
Shifters SRAM 500 TT Bar End Shifter
Crankset FSA Gossamer Pro Triple
Bottom Bracket FSA Road MegaExo
Chainrings 30/39/52
Chain Guard FSA Guard
Cassette SRAM 11/36 10 Speed
Chain KMC
Idler TerraCycle Sport Power Idler 15T
Headsets FSA Zero Stack
Front Tires 406 Schwalbe Marathon Racer
Rear Tire 406 Schwalbe Marathon Racer
*All components are subject to change with an equivalent substitute based on availability
Trail Geometry
Folded Length
Folded Width
Folded Height
Total Length**
Total Width
Total Height |
US 43 in
32.5 in
22 in
73 in
32.5 in
25 in |
metric 1092 mm
826 mm
559 mm
1854 mm
826 mm
635 mm | ||
Wheel Base |
39 in |
|
991 mm |
|
Wheel Track | 29 in |
| 737 mm |
|
Seat Angle |
45/52 deg |
|
|
|
Weight* |
37 lb |
|
16.8 kg |
|
Seat Height |
9 in |
|
229 mm |
|
Seat Width |
14 in |
|
356 mm |
|
BB Height** |
16 in |
|
406 mm |
|
Ground Clearance | 3.25 in |
| 102 mm |
|
Total Height | 25 in |
| 635 mm |
|
Height w/ Seat Folded | 24.5 in |
| 622 mm |
|
Turning Circle | 16.5 ft |
| 5.25 m |
|
Turning Radius | 8.25 ft |
| 2.5 m |
|
Rider Weight Limit | 275 lb |
| 125 kg |
|
Rider X-Seam Range | 39/46 in |
| 99/117 cm |
|
RPDX Demo Trails You Can Test Ride!!
Folding Trail -Lava Red
The folding Trail is a bit lower and a bit narrower than the Villager. RPDX mechanics added a rear rack -perfect for adding saddlebags or a rack top bag. Also added are T-Cycle Assist Arms and oversized mirrors providing a wider field
Trail Geometry
Folded Length
Folded Width
Folded Height
Total Length**
Total Width
Total Height |
US 43 in
32.5 in
22 in
73 in
32.5 in
25 in |
metric 1092 mm
826 mm
559 mm
1854 mm
826 mm
635 mm | ||
Wheel Base |
39 in |
|
991 mm |
|
Wheel Track | 29 in |
| 737 mm |
|
Seat Angle |
45/52 deg |
|
|
|
Weight* |
37 lb |
|
16.8 kg |
|
Seat Height |
9 in |
|
229 mm |
|
Seat Width |
14 in |
|
356 mm |
|
BB Height** |
16 in |
|
406 mm |
|
Ground Clearance | 3.25 in |
| 102 mm |
|
Total Height | 25 in |
| 635 mm |
|
Height w/ Seat Folded | 24.5 in |
| 622 mm |
|
Turning Circle | 16.5 ft |
| 5.25 m |
|
Turning Radius | 8.25 ft |
| 2.5 m |
|
Rider Weight Limit | 275 lb |
| 125 kg |
|
Rider X-Seam Range | 39/46 in |
| 99/117 cm |
|
Folding Trail -Firefly Yellow
Just a couple differences from the red demo above
Short Compact Cranks -provide easier gearing and shorter cranks ideal for shorter riders
Short boom -Our mechanics can shorten ANY boom -and often do- for shorter riders. Catrike also offers Long and Extra-Long booms riders above
Trail Geometry
Folded Length
Folded Width
Folded Height
Total Length**
Total Width
Total Height |
US 43 in
32.5 in
22 in
73 in
32.5 in
25 in |
metric 1092 mm
826 mm
559 mm
1854 mm
826 mm
635 mm | ||
Wheel Base |
39 in |
|
991 mm |
|
Wheel Track | 29 in |
| 737 mm |
|
Seat Angle |
45/52 deg |
|
|
|
Weight* |
37 lb |
|
16.8 kg |
|
Seat Height |
9 in |
|
229 mm |
|
Seat Width |
14 in |
|
356 mm |
|
BB Height** |
16 in |
|
406 mm |
|
Ground Clearance | 3.25 in |
| 102 mm |
|
Total Height | 25 in |
| 635 mm |
|
Height w/ Seat Folded | 24.5 in |
| 622 mm |
|
Turning Circle | 16.5 ft |
| 5.25 m |
|
Turning Radius | 8.25 ft |
| 2.5 m |
|
Rider Weight Limit | 275 lb |
| 125 kg |
|
Rider X-Seam Range | 39/46 in |
| 99/117 cm |
|
Folding Trail Bafang -Electric Blue
Our Demo Bafang Folding Trail includes T-Cycle Assist Arms, Heel Support Pedals and the optional Bafang Light Kit.
If you need shorter cranks, we can swap those out on the fly!
Trail Geometry
Folded Length
Folded Width
Folded Height
Total Length**
Total Width
Total Height |
US 43 in
32.5 in
22 in
73 in
32.5 in
25 in |
metric 1092 mm
826 mm
559 mm
1854 mm
826 mm
635 mm | ||
Wheel Base |
39 in |
|
991 mm |
|
Wheel Track | 29 in |
| 737 mm |
|
Seat Angle |
45/52 deg |
|
|
|
Weight* |
37 lb |
|
16.8 kg |
|
Seat Height |
9 in |
|
229 mm |
|
Seat Width |
14 in |
|
356 mm |
|
BB Height** |
16 in |
|
406 mm |
|
Ground Clearance | 3.25 in |
| 102 mm |
|
Total Height | 25 in |
| 635 mm |
|
Height w/ Seat Folded | 24.5 in |
| 622 mm |
|
Turning Circle | 16.5 ft |
| 5.25 m |
|
Turning Radius | 8.25 ft |
| 2.5 m |
|
Rider Weight Limit | 275 lb |
| 125 kg |
|
Rider X-Seam Range | 39/46 in |
| 99/117 cm |
|
Standard Features
⦁ Padded seat
⦁ Ergonomic adjustable seat back
⦁ Roller wheels for rolling when folded
⦁ Padded wrist rests
⦁ Rear Fender
⦁ Flag Mount & Flag
⦁ Mirrycle Rear View Mirror
⦁ Multi Purpose Clipless Pedals
⦁ Computer Sensor Mount
⦁ No Brake Steer
⦁ Self Centering
⦁ Ackermann Steering Compensation
⦁ Structural Front Boom
⦁ Quick-Release Indexing Boom Clamp
⦁ Aluminum Rod Ends
⦁ Low Friction PTFE Flared Chain Tube
